Alphard Square
Alphard Square
Regular price
£0.00 GBP
Regular price
Sale price
£0.00 GBP
Unit price
per
Taxes included.
Description
- Black as standard, white option as a special
- Available with integrated microwave, emergency or combination
- Also available in round shape
See the Specification Details section below for full specifications.
Looking to further customize this product? Speak to a Lighting Consultant
- Free Shipping on orders over £100
- Delivery in 1-2 weeks
- 30-day Return Policy
Quantity
Couldn't load pickup availability
Collapsible content
Specifications
- Light Source Information : Direct light output · Side light emitted · LED output of 24W delivering 2038 lm · Efficacy of 85lm/W · >83 colour rendering index · 5000K colour temperature as standard · L70 B50 = 70,000 hours | L90 B50 = 25,000 hours · 2-3 bin Epistar LEDs with a ≤4 step Macadam ellipse tolerance
- Design : Black cast aluminium body, IK10 rated · White body as an option · IP65 Rated
- Mounting Options : Surface mounted · Suspended
- Optics : 120° beam angle · Opal TPa rated diffuser
- Dimming : Non-dimmable as standard · Mains/ DALI/ 0-10V / DSI dimming available
- Extras : Integrated microwave sensor available · Integrated Emergency available · Z10 remote control manual or advanced self-test emergency available
- L70 B50 = 70,000 hours L90 B50 = 25,000 hours
- Miscellaneous : 5 year warranty
- IP65 Rated for high humidity areas
- Modern architectural ’rounded square’ styling
- Cast aluminium IK10 rated body
- Epistar LEDs with a ≤4 step Macadam ellipse tolerance
- Surface mounted as standard with optional suspension
- Halo side light emitted
- To specify state : LED square surface mounted circular luminaire with a unique superior design for optimal light diffusion, ideal for decorative interior and exterior applications. Front and halo light emitted through a TPa front and side opal diffuser. Optional integrated microwave presence detector with ON/OFF – as Your Lights' Alphard Square
