Fixed Spotlight For High End Applications
Description
- Discreet size (60mm cut out)
- Narrow white bezel
- Titanium reflector
- Speciality beams
- Opal diffuser for effective glare control
- CRI> 90Ra
- Dimming & emergency customisation options available
- Honeycomb louvre diffuser available
- L70 B50 = 100,000 hours | L90 B50 = 42,000 hours
- Single bin CREE COB with a ≤3 step Macadam ellipse tolerance
Looking to further customize this product? Speak to a Lighting Consultant
- Free Shipping on orders over £100
- Delivery in 1-2 weeks
- 30-day Return Policy
Quantity
Couldn't load pickup availability
Collapsible content
Specifications
- Light Source Information : Direct light output · 6W delivering 592lm · Efficacy of 80lm/W · Drivers supplied · >90 colour rendering index · 3000K colour temperature · L70 B50 = 100,000 hours | L90 B50 = 42,000 hours · Single bin CREE COB with a ≤3 step Macadam ellipse tolerance
- Design : Aluminium body · IP20 rated · Recessed mounting
- Dimensions : ø68 x 64mm
- Cutout : ø60mm
- Optics : PMMA opal diffuser as standard · Bezel finish: white · Reflector finish: titanium · Beam angle: 15 degrees with optional 38 or 55-degree optics · Honeycomb louvre diffuser available -TP(a) rated
- Dimming : Non-dimmable as standard · Mains, DALI, 0-10V, DSI dimming available
- Miscellaneous : 3hr Emergency available · 5 year warranty
- To specify state : 6W discreet architectural LED downlight with cast aluminium body and heatsink. Narrow white bezel with a metallic black reflector. CREE COB with a <3 step Macadam ellipse tolerance – as Your Lights' Pinnacle range.
